09.01 - 1 - BODYWORK AND CENTRAL OUTER TRIM PANELS

Select a part from the list to view details

Select a part from the list to view dimensions

Select a part from the list to view fitment information

Parts List

Ref	Part Number	Description	Price
1	673015435	LH EXTERNAL BODY SIDE ASSEMBLY	$5,513.97 Order
1	673015443	RH EXTERNAL BODY SIDE ASSEMBLY	$5,513.97 Order
2	670157973	LH SIDE MEMBER ASSEMBLY	$0.00 Order
2	670157989	RH SIDE MEMBER ASSEMBLY	$0.00 Order
3	673015440	LH INSERT	$0.00 Order
3	673015448	RH INSERT	$0.00 Order
4	673015531	LH FRONT PILLAR SIDE RAIL ASSEMBLY	$0.00 Order
4	-	LH FRONT PILLAR SIDE RAIL ASSEMBLYOPEN PHD TO ORDER THE COMPONENT	$0.00 Order
4	673015530	RH FRONT PILLAR SIDE RAIL ASSEMBLY	$0.00 Order
4	-	RH FRONT PILLAR SIDE RAIL ASSEMBLYOPEN PHD TO ORDER THE COMPONENT	$0.00 Order
5	673015527	LH FRONT PILLAR MEMBER REINFORCEMENT	$0.00 Order
5	673015432	RH FRONT PILLAR MEMBER REINFORCEMENT	$0.00 Order
6	673015433	WINDSCREEN UPPER CROSS MEMBER ASSEMBLY	$0.00 Order
7	673015434	COMPLETE REAR CROSS MEMBER	$0.00 Order
10	670174430	SCREW	$0.00 Order
11	670214311	SCREW	$0.00 Order
12	custom	ROOF EXTERNAL TRIM	$0.00 Order
13	675002250	NUT	$9.84 Order
14	670036841	ADHESIVE PLUG	$11.08 Order
15	670036842	PLUG	$6.93 In Stock
16	673015528	ROOF PANEL FRONT RIB	$0.00 Order
16	-	ROOF PANEL FRONT RIBOPEN PHD TO ORDER THE COMPONENT	$0.00 Order
17	673015529	ROOF PANEL REAR RIB	$0.00 Order
17	-	ROOF PANEL REAR RIBOPEN PHD TO ORDER THE COMPONENT	$0.00 Order
18	670303964	SCREW	$0.00 Order
19	670174395	SCREW	$0.00 Order
20	670175157	SCREW	$0.00 Order
