| Ref | Part Number | Description | Price | Qty | |
|---|---|---|---|---|---|
| 1 | custom | LH SEAT WIRING HARNESS |
$0.00
Order
|
|
|
| 1 | custom | RH SEAT WIRING HARNESS |
$0.00
Order
|
|
|
| 2 | 673000294 | PUSH-BUTTON SWITCH |
$89.02
Order
|
|
|
| 3 | 673000295 | 8-WAY SWITCH |
$166.01
Order
|
|
|
| 3 | 673000296 | 8-WAY SWITCH |
$151.40
Order
|
|
|
| 4 | 673000293 | LUMBAR SUPPORT ADJUSTMENT JOYSTICK |
$142.56
Order
|
|
|
| 5 | 673000320 | FRONT SEAT BACK FAN |
$800.61
Order
|
|
|
| 6 | 673000321 | SEAT FAN |
$300.31
Order
|
|
|
| 7 |
675000542
Replaced by: #670221098
|
FRONT SEAT SETTING ECU |
$0.00
Order
|
|
|
| 7 |
670035026
Replaced by: #670221098
|
FRONT SEAT SETTING ECU |
$542.35
Order
|
|
|
| 7 | 670221098 | FRONT SEAT SETTING ECU |
$563.91
Order
|
|
|
| 8 | 673000318 | LH SUPPORT |
$57.18
Order
|
|
|
| 8 | 673000319 | RH SUPPORT |
$57.18
Order
|
|
|
| 9 | 670007530 | FRONT SEAT BACK FRAME |
$1,138.88
Order
|
|
|
| 9 | 670007531 | FRONT SEAT BACK FRAME |
$1,117.53
Order
|
|
|
| 10 | 673000229 | FRONT CUSHION FRAME |
$649.48
Order
|
|
|
| 10 | 673000230 | FRONT CUSHION FRAME |
$649.48
Order
|
|
|
| 11 | 673000233 | SCREW |
$18.59
Order
|
|
|
| 12 | 670006705 | SEATBACK REAR PANEL LED LIGHT |
$81.26
Order
|
|
|
| 13 | 673000234 | BRACKET |
$45.74
Order
|
|
|
| 14 | 670006649 | TRIM PLATE |
$19.70
Order
|
|
|
| 15 | 673000325 | SCREW |
$11.40
Order
|
|
|
| 16 | 670006150 | SUPPORT |
$36.01
Order
|
|
|
| 17 | 670007533 | FRONT BRACKET |
$68.85
Order
|
|
|
| 18 | 673000291 | LH SIDE CASING MOUNTING BRACKET |
$81.62
Order
|
|
|
| 18 | 673000292 | RH SIDE CASING MOUNTING BRACKET |
$81.62
Order
|
|
|
| 19 | 670035027 | HEATER-FAN ECU |
$352.77
Order
|
|
|
| 20 | 673000299 | CONTROL UNIT BRACKET |
$27.90
Order
|
|
|
| 21 | 670006706 | AIR VENT |
$82.18
Order
|
|
|
| 22 | 670007272 | LH PROTECTION COVER |
$25.20
Order
|
|
|
| 22 | 670007271 | RH PROTECTION COVER |
$25.20
Order
|
|
|
| 23 | 670006056 | CPL. FRONT SEAT BACK HEATER |
$463.43
Order
|
|
|
| 24 | 670006039 | FRONT SEAT BACK HEATER |
$376.06
Order
|
|
|
| 25 | 670006155 | SBR SENSOR |
$79.57
Order
|
|
|
| 26 | 670006055 | CPL. FRONT SEAT CUSHION HEATER |
$305.86
Order
|
|
|
| 27 | 670006057 | CPL. FRONT SEAT CUSHION HEATER |
$439.26
Order
|
|
|
| 28 | 673000326 | RIVET |
$11.52
Order
|
|
| SVG Path | Qu2016-09-41-1-front-seats-mechanics-and-electronics-4wd410hp.svg |
|---|---|
| SVG Width | 798.801000 |
| SVG Height | 503.400000 |
