| Ref | Part Number | Description | Price | Qty | |
|---|---|---|---|---|---|
| 1 | 673006239 | FRONT CRASH BOX CROSS MEMBER |
$682.20
Order
|
|
|
| 2 | 670038090 | RH FRONT CRASH CROSS MEMBER ASSEMBLY |
$92.28
Order
|
|
|
| 3 | 670038089 | LH FRONT CRASH CROSS MEMBER ASSEMBLY |
$92.28
Order
|
|
|
| 4 |
673008286
Replaced by: #673009228
|
RH COMPLETE FRONT STRUT |
$0.00
Order
|
|
|
| 4 |
673009209
Replaced by: #673009228
|
RH COMPLETE FRONT STRUT |
$0.00
Order
|
|
|
| 4 | 673009228 | RH COMPLETE FRONT STRUT |
$2,094.25
Order
|
|
|
| 5 | 673000375 | COMPLETE RH UPPER STRUT BOX SECTION |
$250.30
Order
|
|
|
| 6 | 670035227 | SCREW AND WASHER |
$10.62
Order
|
|
|
| 7 | 673002684 | RH UPPER STRUT |
$542.58
Order
|
|
|
| 8 | 670039839 | DIAPHRAGM |
$0.00
Order
|
|
|
| 9 | 670036938 | FUSE BOX MOUNTING BRACKET |
$133.74
Order
|
|
|
| 9 | 670104471 | FUSE BOX MOUNTING BRACKET |
$63.19
Order
|
|
|
| 10 |
673008180
Replaced by: #673009229
|
LH COMPLETE FRONT STRUT |
$0.00
Order
|
|
|
| 10 |
673009210
Replaced by: #673009229
|
LH COMPLETE FRONT STRUT |
$0.00
Order
|
|
|
| 10 | 673009229 | LH COMPLETE FRONT STRUT |
$2,173.75
Order
|
|
|
| 11 | 673000376 | COMPLETE LH UPPER STRUT BOX SECTION |
$250.30
Order
|
|
|
| 12 | 670003420 | BRACKET |
$19.95
Order
|
|
|
| 13 | 673008316 | LOWER INSTRUMENT PANEL |
$835.81
Order
|
|
|
| 14 | 670035458 | LOWER FRONT-END MODULE SUPPORT |
$267.70
Order
|
|
|
| 15 | 673000388 | WINDSCREEN LOWER CROSS MEMBER |
$156.00
Order
|
|
|
| 16 | 675000435 | SCREW |
$6.21
Order
|
|
|
| 17 | 670004846 | 24-WAY HOLDER BRACKET |
$21.72
Order
|
|
|
| 18 | 670037229 | SUSPENSION STRUT CONNECTING CROSS MEMBER ASS. |
$546.11
Order
|
|
|
| 20 | 675000471 | SCREW |
$8.00
Order
|
|
|
| 21 | 675000556 | SCREW |
$10.40
Order
|
|
|
| 22 | 670036841 | ADHESIVE PLUG |
$11.08
Order
|
|
|
| 23 | 670036841 | ADHESIVE PLUG |
$11.08
Order
|
|
|
| 24 | 670004843 | PLUG |
$15.89
Order
|
|
|
| 25 | 670004844 | PLUG |
$13.58
Order
|
|
|
| 26 | 675000470 | SCREW |
$7.65
Order
|
|
|
| 27 | 675000382 | SCREWM6X16 |
$10.16
Order
|
|
|
| 28 | 675000421 | SCREW |
$23.55
Order
|
|
|
| 29 | 675000095 | NUTM6 |
$8.64
Order
|
|
|
| 30 | 673002685 | LH UPPER STRUT |
$584.47
Order
|
|
|
| 31 | 670002185 | THREADED RIVET |
$11.10
Order
|
|
|
| 32 | 675000398 | RIVET |
$25.23
Order
|
|
|
| 33 | 675000398 | RIVET |
$25.23
Order
|
|
|
| 34 | 670032695 | RIVET |
$11.52
Order
|
|
|
| 35 | 670032695 | RIVET |
$11.52
Order
|
|
|
| 36 | 670005411 | RIVET |
$5.58
Order
|
|
|
| 37 | 670005395 | THREADED RIVET |
$6.21
Order
|
|
|
| 38 | 670006571 | THREADED RIVET |
$6.21
Order
|
|
|
| 39 | 670002185 | THREADED RIVET |
$11.10
Order
|
|
|
| 48 | 10519527 | WASHER |
$11.10
Order
|
|
|
| 49 | 670032695 | RIVET |
$11.52
Order
|
|
|
| 52 | 675000623 | WELDED STUDM5X14 |
$12.11
Order
|
|
|
| 54 | 675000628 | WELDED STUDM6X25 |
$12.71
Order
|
|
|
| 55 |
670107233
Replaced by: #670155028
|
RH FRONT DOME |
$0.00
Order
|
|
|
| 55 | 670155028 | RH FRONT DOME |
$1,233.23
Order
|
|
|
| 55 |
670034237
Replaced by: #670155028
|
RH FRONT DOME |
$0.00
Order
|
|
|
| 56 | 670107239 | LH FRONT DOME |
$612.99
Order
|
|
|
| 56 |
670034243
Replaced by: #670107239
|
LH FRONT DOME |
$0.00
Order
|
|
|
| 57 | 670032695 | RIVET |
$11.52
Order
|
|
|
| 58 | 670030073 | PLUG |
$9.72
Order
|
|
|
| 59 | 673008198 | LONGITUDINAL MEMBER CONNECTING CROSS MEMBER |
$566.83
Order
|
|
|
| 60 | 675000467 | SCREWM 8X20 |
$80.70
Order
|
|
|
| 61 | 670152736 | PLUG |
$0.00
Order
|
|
